GALILEO EXTRA
OIL MIST COLLECTION & FILTRATION
The Galileo Extra is a patented centrifugal filter from LOSMA for mist generated from neat oil and emulsions used in machine tools, also suitable for use when particulates are present.
The Galileo Extra is available in five models with flow rates from 325 to 3.500 m3/hr.
Patented in Italy, Europe, USA, China and Japan.
Technical Information
X View filter condition monitoring system
The new X-VIEW sensor is able to detect the progressive clogging state of the Galileo Extra filters, signalling three main operating phases - Green - Yellow - Red.
X-VIEW sensor can be positioned on Galileo Extra or in any other part of the machine tool where the operator is more comfortable reading the indicator. Thanks to the Self-learning button, it automatically sets itself to the initial values, making installation extremely easy.
X-VIEW works with all accessories (G-Guard Plus, G-Clipper Plus, Horizontal input) and it can be integrated with the CNC of the machine tool (IoT Ready version), providing feedback in real time on the air filter conditions.
The X-View comes in two version standard LED view and an IoT ready version - see data sheet for additional Information.
High Efficiency Multistage Filtration
The combination of the impeller, centrifugal action and a high efficiency multilayer filter guarantees a high level of filtration can be achieved. The multilayer Filters are positioned after the centrifugal action of the impeller which reduces the particulate loading on the filters ensuring a long service life and reduced running costs.
High Efficiency energy saving motors
Inspired by Blue Philosophy, the Galileo Extra uses high efficiency energy saving motors which ensure reduced energy consumption.
High efficiency filter materials
The filter materials used within the Galileo Extra are stress tested within LOSMA laboratories to check for compatibility, with the different types of neat oils and emulsions that are available on the open market.
Innovative open bladed impeller
The Galileo Extra is fitted with a special impeller which is designed to prevent material settlement upon its surface. This helps to prevent vibration and noise that is associated with material settlement upon impeller surfaces.
Innovative design for quick and easy servicing.
The Galileo Extra has been designed to allow quick access to the main Internal filters ensuring servicing and maintenance can be undertaken with minimum downtime.
Optional
High Efficiency "G-Guard" Pre-Filtration module
The LOSMA G-Guard Pre-filtration module is used as an initial pre-separation unit for applications with a high dust / swarf loading. The G-Guard effectively removes dust, swarf and chips from oil mist laden process air which prevents premature failure of the main filters. The Guard contains a reusable / washable mesh filter. The Galileo extra filtration units mounts directly to the to of the G-Guard unit.
High Efficiency " Clipper Plus" After Filter
The Galileo Extra is available with an optional “Clipper” after filter cartridge for micro-mist, smoke & vapours. With the optional "Clipper" after filter fitted, filtration efficiency is increased to 99.97%.
.png/:/cr=t:0%25,l:0%25,w:100%25,h:100%25/rs=w:600,h:300,cg:true)
Horizontal Input
The Galileo Extra can be connected to a horizonal inlet plenum chamber, Ideal for installation at a lower level in order to facilitate easier routine maintenance and inspection.
